Spare Parts
| Machine Metric Tons | Bucket Size |
Top (overall) width/In | Base width/In |
Weight/Lbs |
Top (overall) width/mm | Base width/mm |
Weight/KG |
8-12 |
48 x 12 | 48 | 12 | 739 | 1,219 | 305 | 335 |
| 54 x 18 | 54 | 18 | 787 | 1,372 | 457 | 357 | |
| 12-20 |
54 x 12 | 54 | 12 | 983 | 1,372 | 305 | 446 |
| 60 x 18 | 60 | 18 | 1,045 | 1,524 | 457 | 474 | |
| 66 x 24 | 66 | 24 | 1,217 | 1,676 | 610 | 552 | |
20-25 |
63 x 20 | 63 | 20 | 1,371 | 1,600 | 559 | 622 |
| 69 x 24 | 69 | 24 | 1,565 | 1,753 | 610 | 710 | |
25-30 |
66 x 20 | 66 | 20 | 1,704 | 1,676 | 508 | 773 |
| 72 x 24 | 72 | 24 | 1,907 | 1,829 | 610 | 865 | |
30-40 |
74 x 20 | 74 | 20 | 2,513 | 1,880 | 508 | 1,140 |
| 80 x 24 | 80 | 24 | 2,740 | 2,032 | 610 | 1,243 |
