Skid Steer Loader

ITEMS	SPECIFICATIONS	ITEMS	SPECIFICATIONS
Engine Brand	LONCIN/RATO/KOOP	Height at Maximum Extension/mm	2450
Rated Power/HP	15-18KW	Height To the the bucket pin /mm	1870
Rated Speed/rpm	3600	Vehicle height	1350
	2	Maximum Height as Lay the bucket flat/mm	1810
Air intake way	Naturally Aspirated	Total length without appendages/mm	1680
Displacement/cc	639	Length With standard bucket /mm	2206
Emissions Standards	EUR 5	Maximum height unloading Angle	34
Rated Operating Capacity/Kg	300	Dumping Height/mm	1510
Maximum Operating Capacity/Kg	400	Discharge Distance/mm	450
Maximum Breakout Force/KN	450	The flip Angle of the bucket on the ground	27
Bucket Capacity/m3	0.12	Bucket flip Angle at highest Pos.	114
Driving Speed/ km/h	0-6	Wheel Base/mm	850
Total Cycling Time/s	9	Ground Clearance/mm	150
System Operating Pressure /bar	17-21	Tail Length/mm	280
Fuel Tank Capcity/L	10	Wheel base (standard tire) /mm	720
Operating Weight/Kg	1200	Vehicle width (standard tire) /mm	1100
Tyre Size	18*72	Bucket width/mm	1000
