Forklift

Item	General	Basic Model			Unit	CPCD50	CPCD60	CPCD70
1		Power type				Diesel
2		Rated capacity			kg	5000	6000	7000
3		Load centre			mm	600
4	Characteristic&Dimension	Lift height			mm	3000
5		Free lift height			mm	195	200	205
6		Fork size		LxWxT	mm	1220x150x55	1220x150x60	1220x150x65
7		Fork regulating range		Min./Max.	mm	300/1845
8		Mast tilt angle		F/R	Deg	6°/12°
9		Front overhang			mm	590
10		Rear overhang			mm	600	675	740
11		Min. ground clearance(Bottom of mast)			mm	200
12		Overall dimensions		Length to face of fork (without fork)	mm	3440	3515	3580
13				Overall width	mm	1995
14				Mast lowered height	mm	2500	2500	2625
15				Mast extended height (with backrest)	mm	4420
16				Overhead guard height	mm	2450
17		Turning radius(outside)			mm	3250	3300	3370
18		Min. right angle stacking aisle width (add load length and clearance)			mm	2960	3000	3040
19	Performance	Speed		Travel(Unladen)	km/h	26/28	26/28	26/28
20				Lifting(Laden)	mm/s	460/500	460/500	380/420
21				Lowering(Laden)	mm/s	500
22		Max. Drawbar pull(Laden/unladen)			KN	53	53	52
23
		Max. Gradeability(Laden)			%	22	21	20
24
	Chassis	Tyre		Front		8.25-15-14PR
25				Rear		8.25-15-14PR
26		Tread		Front	mm	1470
27				Rear	mm	1700
28		Wheelbase			mm	2250
29	Weight	Self weight			kg	8080	8740	9450
30		Weight Distribution	Laden	Front Axle	kg	11250	12680	14150
31				Rear Axle	kg	1830	2060	2300
32			Unladen	Front Axle	kg	3640	3930	4250
33				Rear Axle	kg	4440	4810	5200
34	Battery	Battery	Voltage/Capacity		V/Ah	2x12/80
35	Transmission	Transmission	Manufacture			China
36			Type			Powershift
37			Stage	F/R		2/2
38		Operating pressure(For attachments)			MPa	19.5
