Bulldozer

  • Description
Model HD16R
Operating Weight 18100 kg
Overall Dimenssions 5256×4153×3072 mm
Blade type Straight-tilt
Dozing capacity 8.3 m³
Blade width 4145 mm
Blade height 962 mm
Blade max.drop below ground 488 mm
Blade max.tilt adjustment 730mm
Grade ability 30°
Engine
Model Weichai WP10G178E25
Rated Power 131/1850 Kw/rpm
Cylinder number-bore×stroke 6-126×130mm
Piston displacement 9.726L
Mini fule consumption 214g/kw.h
Max torque 830/1000-1200 N.m/rpm
Cooling Type Water
